Maximum 112 IOs for user defined purposes on FX18 Hirose connectors. All differential pairs are length matched on the module. 2 x GTP available on 2x SATA connectors. Dual Port 100BASE-T Ethernet (Daughter Board). FPGA: Spartan-6 XC6SLX45T in -3FGG484 package (Other devices available at request). Galatea is shipped with a dual port 100BASE-T Ethernet Module and an IO Expansion Module pre-installed. A rich set of off-the-shelf expansion modules are available at. Two high speed expansion connectors are available on board for the purpose of adding additional features to the board by using custom or off-the-shelf daughter boards. This board features Xilinx XC6SLX45T (or larger) – FGG484 FPGA. Galatea is an easy to use FPGA Development board featuring Xilinx Spartan-6 FPGA with x1 PCIe interface and two 1Gb DDR3 SDRAM devices. Documentation, Reference Designs, and KB articles. Industry standard 100mil (2.54mm) headers for IO access. USB, FPGA, and DDR3 in very compact form factor. With Skoll, the complex parts of the design are already taken care of you so you can focus on your own application and achieve faster time to market. With the compact form factor and IO accessibility on industry standard 2.54mm (100mil) headers, Skoll is a great choice for embedding FPGA, DDR3 and USB in your system with ease. Skoll is easy to use USB FPGA module with DDR3 SDRAM featuring Xilinx Kintex 7 FPGA. Channel B can be used for custom applications. FT2232H Channel A is dedicated for SPI Flash /JTAG Programming. High-Speed USB 2.0 interface for On-board flash programming. Flash memory: 128 Mb Quad bit SPI flash memory (N25Q128A13EF840E). FPGA: XC7K70T in FBG484 package, Speed Grade: 1. Skoll provides user flexibility in adding their own peripherals though IO Expansion Headers. The second FTDI channel can be used to develop custom high data-rate USB based applications.
#100 mhz clock mini zed download
No programmer or special down loader cable is needed to download the bit stream to the board. The high-speed USB 2.0 interface provides fast and easy configuration download to the on-board SPI flash. This development board features Xilinx XC7K70T FPGA with FTDI’s FT2232H Dual-Channel USB device. It is specially designed for development and integration of FPGA based accelerated features to other designs. Skoll Kintex 7 FPGA Development Board is easy to use FPGA Development board featuring Kintex 7 FPGA. Other FPGA configurations are available upon request. This board features Xilinx XC7K160T– FBG676 FPGA. Nereid is easy to use FPGA Development Board featuring Xilinx Kintex-7 FPGA with x4 PCIe interface and 4GB DDR3 SDRAM.
Educational tool for Schools and Universities. Development and testing of custom embedded processors. All differential pairs are length matched on the board. JTAG header for programming and debugging. Can be powered from PCIe slot or from an external power supply. Onboard voltage regulators for single power rail operation.
Maximum 153 IOs for user-defined purposes on FMC connector.128 Mb QSPI flash memory (N25Q128A13ESE40E) for Configuration and optional data storage.4 lane PCIe Gen2.0 (5GT/s) interface at maximum 2GB/s.FPGA: Kintex-7 XC7K160T-1 FBG676 package (Other devices available at request).The board features High Pin Count (HPC) high-speed FMC connector for the purpose of adding additional features to the board by using custom or commercial-off-the-shelf daughter boards.
featuring Xilinx Kintex-7 FPGA with x4 PCIe interface and 4GB DDR3 SDRAM. We are offering a wide range of Nereid Kintex 7 PCI Express FPGA Development Board.
